MOTOAZADA YAMAHA 3+1 VELOC. CON MOTOR MX-200

YAMAHA

PRO TILLER MX-175, 3+1 SPEED , DRY CLUTCH, GEAR BOX

REF. MXT-1300
Compatible brands:
YAMAHA
Type: ORIGINAL
EAN Code: 8434898154439


Versatile machine equipped with a Yamaha MX-200 6.5 HP engine with oil bath filter and a gearbox made of steel with four speeds (3 front + 1 rear) and clutch transmission.

Indicated for demanding users or large areas of land.

Main features:

  • Front transport wheel included.
  • Handlebar adjustable both in height and on the sides.
  • Dampening system at the base of the handlebar.
  • Oil bath filter installed on the engine.
  • Professional gearbox with seal covers.
  • 6 cutters with a total of 24 blades and 2 protective plates.
  • Removable protective fins.

ENGINE
MODEL MX-200
START Manual
AIR FILTER Oil bath.
FUEL TANK CAPACITY 3.9 l.
OIL TANK CAPACITY 0.6 l. - SAE 10W30

TRANSMISSION
TRANSMISSION BOX Steel
SPEEDS 3 Forward + 1 Reverse
TRANSMISSION SYSTEM Clutch (dry clutch)
BLADE SHAFT Hex. 27 mm.

TILLING SYSTEM FEATURES
BLADES
 24 blades + 2 discs
WORKING WIDTH
 500 - 900 mm.
WORKING DEPTH
 150 - 300 mm.

WEIGHT
WEIGHT (empty) 85 Kg.

IMPORTANT NOTICE
Basic assembly by the customer is required
The machine is supplied WITHOUT GASOLINE OR OIL in the engine
The machine is supplied WITHOUT OIL in the transmission box
