TRACKED MINIDUMPER 350 KG. HONDA GX-160 ENGINE
REF. TP-280
EAN Code:
8435556435433
Tracked mini dumper with Honda GX-160 5.5 HP engine, ideal for gardening, agriculture, material transport, and construction work.
Its dimensions, high load capacity, and maneuverability make it the perfect replacement for the traditional handcart.
It features a transmission box with 3 speeds (2 forward and 1 reverse) and a tilting dump bed with a maximum load capacity of up to 350 kilograms.
Its rubber track traction allows it to move through the most challenging areas, even when fully loaded.
| ENGINE |
| MODEL | Honda GX-160 |
| POWER | 5.5 HP - 163 cc |
| START | Manual |
| AIR FILTER | Dry filter |
| FUEL TANK CAPACITY | 3.1 l. |
| OIL TANK CAPACITY | 0.58 l. - SAE 10W30 |
| TRANSMISSION |
| TYPE | Manual |
| TURNING SYSTEM | Locking turn |
| SPEEDS | 3 speeds - (2 Forward + 1 Reverse) |
| FORWARD SPEED | 2.45 - 4.00 Km/h. |
| REVERSE SPEED | 2.45 Km/h. |
| OIL CAPACITY | 0.8 l. - SAE 80W90 |
| PLATFORM |
| DIMENSIONS (L x W x H) | 900 x 650 x 250 mm. (closed) |
| TILTING | Manual operation |
| LOAD CAPACITY - On flat terrain - | 300 Kg. (MAX) |
| PLATFORM OPENING | Up to 950 mm. |
| TRACTION |
| TYPE | Rubber tracks |
| TRACK TENSION | By spring |
| WEIGHT, DIMENSIONS, and SOUND LEVEL |
| WEIGHT (Dry) | 160 Kg. |
| DIMENSIONS L x W x H | 171 x 65 x 98 cm. |
| SOUND LEVEL | 93 dB |
| IMPORTANT NOTICE |
| The machine is supplied WITHOUT GASOLINE OR OIL in the engine |
| The machine is supplied WITHOUT OIL in the transmission box |
